25w Open Frame Type 5V 24V Switch Mode Power Supply Unit Design

The PS-25 25W open-frame switch mode power supply provides efficient power solutions with output voltages of 5V, 12V, 15V, 24V, and 48V. With 3000V isolation, this reliable unit is perfect for use in industrial, medical, and communication systems. Its compact design (76.2mm x 50.8mm x 24mm) allows for easy integration into various applications, offering safety, efficiency, and performance.

Product Features:

Multiple output voltages: 5V, 12V, 15V, 24V, 48V DC
Input voltage: 85-264V AC (127-370V DC)
High isolation: 3000V DC
Open-frame design (76.2mm x 50.8mm x 24mm)
High efficiency for energy savings
Ideal for industrial, medical, and telecom applications
Compact size for easy PCB mounting
Reliable and consistent performance in demanding environments

25W Open Frame Type 5V 24V Switch Mode Power Supply Unit Design

The PS-25 is a versatile and reliable 25W open-frame switch mode power supply unit designed to meet the demanding requirements of various applications. With a wide input voltage range of 85-264V AC (127-370V DC), it offers multiple output voltages including 5V, 12V, 15V, 24V, and 48V DC, making it ideal for a wide range of electronic systems. The PS-25 features a 3000V DC isolation, ensuring safety and robust performance in critical environments.

AC - DC Open Frame Type 15W - 420W

part number	power	Vin(dc)	Vout(dc)	isolation(vdc)	size(mm)	package	Datasheet
PS-15	15w	85-264vac*127-370vdc	3.3V/5V/7.5V/12V/15V/24V/36V/48V	3000	63.545.724mm	open frame	Download PS-15
PS-25	25w	85-264vac*127-370vdc	5V/12V/15V/24V/48V	3000	76.250.824mm	open frame	Download PS-25
PS-35	35w	85-264vac*120-370vdc	5V/12V/24V/48V	3000	76.250.824mm	open frame	Download PS-35
PS-45	45w	85-264vac*120-370vdc	5V/12V/15V/24V/48V	3000	76.250.824mm	open frame	Download PS-45
PS-65	65w	85-264vac*120-370vdc	12V/15V/24V/27V/36V/48V	3000	101.650.829mm	open frame	Download PS-65
PS-65E		90-264vac*127-370vdc	5V/7.5V/12V/15V/24V/36V/48V	3000	101.650.829mm	open frame	Download PS-65E
PS-150	150w	85-264vac	3 .3V/5V/12V/15V/24V	3000	63.545.715mm	open frame	Download PS-150
PFS-150	150w	85~264vac	5V/12V/15V/24V/48V	4000	76.250.830mm	open frame	Download PFS-150
PFS-220	220w	80~264vac	5V/12V/15V/24V/48V	4000	76.250.830mm	open frame	Download PFS-220
PFS-220-24AOI	220w	80-264vac	24v	4000	12776.229mm	open frame	Download PFS-220-24AOI
HPS-15	15w	85-264vac*100-370vdc	12V/15V/24V/27V/36V/48V	4000	101.650.829mm	open frame	Download HPS-15
HPS-35	35w	85-264vac*100-370vdc	12V/15V/24V/27V/36V/48V	4000	101.650.829mm	open frame	Download HPS-35
HPS-45	45w	85-264vac*100-370vdc	12V/15V/24V/27V/36V/48V	4000	101.650.829mm	open frame	Download HPS-45
HPS-65	65w	85-264vac*100-370vdc	12V/15V/24V/27V/36V/48V	4000	12776.235mm	open frame	Download HPS-65
HPS-120	120w	85-264vac*100-370vdc	12V/15V/24V/27V/36V/48V	4000	12776.235mm	open frame	Download HPS-120

This power supply is perfect for applications in industrial automation, telecommunications, consumer electronics, medical devices, security systems, and lighting. The compact open-frame design (76.2mm x 50.8mm x 24mm) allows for easy integration into existing systems, and its high efficiency makes it an energy-efficient solution for both low and medium power needs.

Designed to meet stringent industry standards, the PS-25 supports applications in industrial control, home electronics, security, and other sectors requiring reliable power solutions. It’s ideal for use in devices like sensors, LED lighting, medical equipment, and communication devices, ensuring stable and consistent performance in all conditions.

For further information, visit our AC-DC Open Frame Power Supplies to explore our wide range of power supply solutions for your needs.
